Specifications
Part Number: FF25017A1
Tank Type: AUXILIARY
Capacity: 150L
Filler Point: Y FILLER
Fuel Supply Method: TRANSFER TO MAIN TANK
Tank Location: BEHIND REAR AXLE
Fitting Time: 6 hours
Modifications: MUST REMOVE SPARE WHEEL
Key Features of a Brown Davis Auxiliary Fuel Tank
- Designed to increase vehicle’s fuel capacity to the max.
- Longitudinal and lateral baffling system to prevent fuel slosh and to
strengthen tank structure - Gusseted brackets with double thickness pads to spread tank mounting loads
- Roll over check valve and expansion box for fuel expansion and venting
- Fast fill breather for rapid filling and to reduce bowser shut off
- Filler tube connect to stock or a seperate filler tube is supplied.
- Cushion clamps to retain fuel lines to prevent damage and kinking
- Magnetic drain plug, horizontal and flush mounted to prevent damage
Replacement System
Replacement Long range tanks are designed to replace the vehicle standard
fuel tank with an increased fuel capacity. The tank is a simple bolt in
solution to increase your vehicles driving range. On the current model dual
cab ute range the fuel capacity increase is around 100%. Replacement fuel
tanks are designed to minimise vehicle modifications utilising the standard
fuel gauge, pump assembly and fill point for a simple installation. All
Brown Davis fuel tanks come with a flush mounted drain plug for easy
draining in the event of contaminated fuel. The tanks come with all parts
and hardware supplied.
fuel tank with an increased fuel capacity. The tank is a simple bolt in
solution to increase your vehicles driving range. On the current model dual
cab ute range the fuel capacity increase is around 100%. Replacement fuel
tanks are designed to minimise vehicle modifications utilising the standard
fuel gauge, pump assembly and fill point for a simple installation. All
Brown Davis fuel tanks come with a flush mounted drain plug for easy
draining in the event of contaminated fuel. The tanks come with all parts
and hardware supplied.
Aluminised Steel Long Range Fuel Tanks
Brown Davis Aluminised Steel long range fuel tanks are constructed from 2mm
aluminium coated cold rolled steel, to ensure maximum strength and
durability. This gauge of steel is sufficiently resistant to impact damage
that additional tank guards are not necessary. The aluminium coating on the
specific steelused by Brown Davis, offers the best of both worlds with the
strength of steel and the anti corrosion properties of aluminium.
aluminium coated cold rolled steel, to ensure maximum strength and
durability. This gauge of steel is sufficiently resistant to impact damage
that additional tank guards are not necessary. The aluminium coating on the
specific steelused by Brown Davis, offers the best of both worlds with the
strength of steel and the anti corrosion properties of aluminium.
